Technical Data

cutting width51 cm
maximum grass height “mulching”20 cm
engine manufacturerAS-Motor
engine designationAS 165 ES
1-cyl.engine, 4-stroke / 2-stroke /
maximum power4,4/6,0 kW (hp)
rated power2,8/3,8 kW (hp)
rated speed2800 rpm
third crankshaft bearing for engine protection
100% mulching function
additional side discharge
cutting height40 – 90 mm
central cutting height adjustment
cutting height adjustment, number of levels6
rear-wheel drive
number of gearsVario
max. speed4,3 km/h
Handlebar adjustment: height
tank capacityl
dimension L/W/H139x55x100 cm
weight48 kg
Changes in technology, equipment and price are reserved. Of information or illustrations no claims can be derived.


2-stroke power for mowing and mulching

The AS 510 ProClip 2in1 2T A is equipped with the world’s only 2-stroke engine that meets the requirements stipulated by the EU Emissions Directive 97/68/EC. The AS 2-stroke engine maintains engine lubrication regardless of position, enabling work on inclines of 40 degrees and more without the risk of engine damage. In addition, the AS 2-stroke engine is factory-equipped with an EasyStart function; the CDI digital ignition system cuts the rpms required to start in half. The 2-stroke engine’s high torque ensures that the power of the AS 510 ProClip 2in1 2T A is not interrupted.

A third crankshaft bearing and friction discs on the mulching blade protect the engine in the event of unseen obstacles. A variator allows the speed to be conveniently adjusted from 2.1–4.3 km/h while in motion. Double ball-bearing front wheels and rear wheel drive provide easy handling. The front wheels’ special wedge shape minimizes impact on the grass, leading to extremely uniform cutting results. Cutting height can be adjusted from 40–90 mm via a spring-supported system.

The AS 510 ProClip 2in1 2T ES A is a combination machine that allows the operator to choose between mowing and mulching. The machine is factory-equipped with an easy-to-mount mulch plate, and side discharge deflector for grass up to 50 cm high. Ideal for overgrown lawns and extended mowing intervals on natural meadows.

Mulching saves time and money

The specially-designed mulching blade cleanly cuts grass up to 20 cm high and simultaneously generates an airflow that whirls the cuttings in the mulching unit. The mulching blade’s three cutting edges chop and mulch the grass several times. The cuttings then sink into the turf, forming a layer of mulch that both fertilises and protects the lawn from drying out. The AS 510 ProClip 2in1 2T A saves 30% more time when compared with collection bag lawn mowers by avoiding the need to empty the collection bag as well as cost-intensive cuttings disposal.
Mow or mulch: The AS 510 ProClip 2in1 2T A is factory-equipped with an easy-to-mount mulch plate and side discharge deflector. Thus grass up to 50 cm high can be mowed with side discharge.
